25mm - 130mm Bugle Head Screw Drywall Screws For Woodworking

Brand Name:	YONGBIAO
Model Number:	DIN18182
MOQ:	1tons
Price:	1-3tons:1400USD; 3-5tons: 1350USD
Packaging Details:	Carton Box/Pallet/Customized
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

ZHEJAING CHINA

Certification:

ISO9001

Name:

Bugle Head Screw

Rust Resistant:

Head Style:

Bugle Head

Sharpness:

Thread Type:

Coarse

Durability:

Quantity:

10000pieces

Thread Diameter:

3.5-5.5mm

Supply Ability:

200Tons/month

Highlight:

25mm Bugle Head Screw

130mm Bugle Head Screw

Drywall Screws For Woodworking

Product Description

Coarse Thread Bugle Head Screw Corrosion Resistant Rust Resistant Drywall Screws

Company Certificate:

25mm - 130mm Bugle Head Screw Drywall Screws For Woodworking 4

Product Description:

Drywall Screws Application:

Drywall screws (self tapping screws) are the main fasteners used to fix

gypsum boards in indoor decoration, especially suitable for ceiling and

partition construction.During installation, it is necessary to use fine thread

dry wall nails (suitable for light steel keel) or coarse thread drywall screws

(suitable for wooden keel), with a length of usually 25-35mm (single-layer

board) or 38-50mm (double-layer board).During construction, screws

should be evenly inserted into the keel at a spacing of 15-20cm, and the

screw's head should be slightly recessed (1-2mm below the board

surface) for subsequent coating coverage.For the ceiling, it is

recommended to increase the spacing to 10-15cm to enhance load-

bearing capacity; A distance of 10-15cm should be reserved at the edge of

the partition wall to avoid cracking.Normal use of black phosphating

drywall nails can be replaced with galvanized or stainless steel materials

in damp areas such as kitchens and bathrooms to ensure long-term

stability.

Drywall Screws Advantage:

Easy installation and high construction efficiency

Drywall screws are self tapping designs that do not require pre drilling and can

directly penetrate gypsum boards and keels (wood/light steel). If carbon steel or

410 stainless steel is used as the material, an electric screwdriver can be used to

quickly fix them in bulk, improving construction efficiency.

Cost economy

Drywall screws are inexpensive and have uniform specifications, making them

suitable for large-scale construction and reducing material and labor costs.

High strength fixation

The thread design (coarse/fine) of drywall screws is suitable for different keel

materials, with strong grip to avoid loosening or sagging of gypsum boards.Dry wall

screws, also known as horn screws, have a "horn shaped" design that disperses

pressure and reduces the risk of surface cracking on gypsum boards.

Technical Parameters:

25mm - 130mm Bugle Head Screw Drywall Screws For Woodworking 11

d		3.5	4	4.3	5.1	5.5
d	Max	3.7	4	4.3	5.1	5.5
d	Min	3.4	3.7	4	4.8	5.2
dk	Max	8.5	8.5	8.5	8.5	8.5
dk	Min	8.14	8.14	8.14	8.14	8.14
L	25-130mm

Drive Style	Phillips
Corrosion Resistance	Yes
Thread Diameter	3.5-5.5mm
Head Style	Bugle Head
Thread Type	Coarse
Length	25-130mm

This table describes the technical parameters of a black fine thread gypsum board drywall screw or wood drywall screw or black drywall screw with bugle head that has a length of 25-130mm, a thread diameter of 3.1-5.2mm, a coarse thread type, high sharpness, and high durability.

Application:

25mm - 130mm Bugle Head Screw Drywall Screws For Woodworking 12

Packaging:


Carton Packaging	Outer Cartonbox Packaging	Pallet Packaging
Bolts are packed in neutral packaging boxes, with standard quantities arranged in small cartons. The exact number of units per carton will be confirmed with the customer to align with their specific requirements. Customized packaging configurations are available upon request.	The small cartons are then consolidated into larger master cartons for secure transportation and storage. The quantity per master carton can be customized based on client specifications or aligned with standard logistical requirements.	The palletized units are securely wrapped with waterproof film and reinforced with packaging straps. Customer-specific shipping marks or labels are affixed to each pallet, ensuring clear identification and compliance with logistics requirements. This final packaging stage guarantees weather-resistant protection and stability during transportation.
