DIN968 Yellow Zinc Plated Self Tapping Screw for Wood Furniture

Brand Name:	YONGBIAO
Model Number:	DIN968 Tapping Screw
MOQ:	800-1000KG
Price:	0.01-0.05
Packaging Details:	Plastic Bag / Paper Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Certification:

ISO 9001

Customized Support:

OEM, ODM

Type:

Self Tapping Screw

Suraface Treatment:

Zinc Plated

Compatibility:

Standard Drill/Driver

Surface Treatment:

Zinc Plated

Head Shape:

Pan Head

Color:

Yellow,White

Suitable For:

Wood Or Furniture

Highlight:

yellow zinc plated self tapping screw

wood furniture self tapping screw

DIN968 self tapping screw

Product Description

DIN968 Plastic Self Tapping Screw with Yellow Finish and Customized Support OEM

Product Specifications

Attribute	Value
Customized Support	OEM, ODM
Type	Self Tapping Screw
Surface Treatment	Zinc Plated
Compatibility	Standard Drill/Driver
Head Shape	Pan Head
Color	Yellow, White
Suitable For	Wood Or Furniture

Product Overview

DIN968 is a standard for cross-groove pan head self-tapping screws established by the German Institute for Standardization (DIN). This standard is commonly utilized for securing connections between metal sheets and non-metallic materials.

The groove type of DIN968 self-tapping screws conforms to the cross-groove design, with options such as H-type or Z-type. The screw can have a pointed tail (C-type) or a flat tail (F-type), making it suitable for tapping into hard materials. The head of the screw is crafted as a Pan Head structure featuring gaskets, and it comes in diameter specifications ranging from ST2.9 to ST6.3.

Key Features

DIN968 self-tapping screws are commonly manufactured using carbon steel (with a surface that may be galvanized or nickel-plated) and stainless steel (specifically SUS304 for corrosion resistance). The carbon steel variation typically belongs to grade 8.8 and boasts a minimum tensile strength of 400MPa, while the stainless steel variant of grade A2-70 must exhibit a strength of at least 700MPa.

The technical specifications of DIN968 self-tapping screws align with the international standard ISO 7049, ensuring consistency and compatibility in terms of their design and performance characteristics.

Technical Parameters

Screw Thread d	ST2.2	ST2.9	ST3.5	(ST3.9)	ST4.2	ST4.8	ST5.5	ST6.3
P (Pitch)	0.8	1.1	1.3	1.3	1.4	1.6	1.8	1.8
a (max)	0.8	1.1	1.3	1.3	1.4	1.6	1.8	1.8
dk (max=nominal size)	4.2	5.6	6.9	7.5	8.2	9.5	10.8	12.5
dk (min)	3.9	5.3	6.54	7.14	7.84	9.14	10.37	12.07
k (max=nominal size)	1.8	2.2	2.6	2.8	3.05	3.55	3.95	4.55
k (min)	1.55	1.95	2.35	2.55	2.75	3.25	3.65	4.25
y (max) Type C	2	2.6	3.2	3.5	3.7	4.3	5	6
y (max) Type F	1.6	2.1	2.5	2.7	2.8	3.2	3.6	3.6
Socket No.	1	1	2	2	2	2	3	3
M1 ≈	2.6	3	4.2	4.4	4.6	5	6.5	7.1
M2 ≈	2.4	2.9	3.9	4.1	4.3	4.7	6.2	6.7

Applications

In various applications such as electrical enclosures, building curtain walls, medical devices, and more, DIN968 self-tapping screws are frequently utilized for light-duty connections. These self-tapping screws feature a built-in pad design that improves force distribution and is well-suited for preventing loosening in thin plates.

The DIN968 self-tapping screws are popular for their ability to provide secure connections in a variety of settings. Their unique pad design ensures that forces are evenly distributed, making them ideal for meeting the anti-loosening needs of thin plates in different industries.

Certifications

Packaging Options

Carton Packaging

Outer Cartonbox Packaging

Pallet Packaging

Bolts are packed in neutral packaging boxes, with standard quantities arranged in small cartons. The exact number of units per carton will be confirmed with the customer to align with their specific requirements. Customized packaging configurations are available upon request.

The small cartons are then consolidated into larger master cartons for secure transportation and storage. The quantity per master carton can be customized based on client specifications or aligned with standard logistical requirements.

The palletized units are securely wrapped with waterproof film and reinforced with packaging straps. Customer-specific shipping marks or labels are affixed to each pallet, ensuring clear identification and compliance with logistics requirements. This final packaging stage guarantees weather-resistant protection and stability during transportation.
