DIN968 Zinc Plated Certification for Surface Treatment Meeting Customer Requirements

Brand Name:	YONGBIAO
Model Number:	DIN968 Tapping Screw
MOQ:	800-1000KG
Price:	0.01-0.05
Packaging Details:	Plastic Bag / Paper Box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Certification:

ISO 9001

Compatibility:

Standard Drill/Driver

Application:

Wood, Metal, Plastic, Etc.

Suitable For:

Wood Or Furniture

Port:

Shanghai Or Ningbo

Customized Support:

OEM, ODM

Color:

Yellow,White

Type:

Self Tapping Screw

Surface Treatment:

Zinc Plated

Highlight:

zinc plated self tapping screw

certified self tapping screw

surface treatment self tapping screw

Product Description

DIN968 Zinc Plated Certification for Surface Treatment Meeting Customer Requirements

Product Specifications

Attribute	Value
Compatibility	Standard Drill/Driver
Application	Wood, Metal, Plastic, Etc.
Suitable For	Wood Or Furniture
Port	Shanghai Or Ningbo
Customized Support	OEM, ODM
Color	Yellow, White
Type	Self Tapping Screw
Surface Treatment	Zinc Plated

Product Overview

DIN968 Overview: DIN968 is a standard for cross groove pan head self tapping screws developed by the German Institute for Standardization (DIN). These screws are commonly used for fastening connections between metal sheets and non-metallic materials.

Key Features

Groove type: Cross groove (H-type or Z-type variations)
Tail options: Pointed tail (C-type) or flat tail (F-type)
Head design: Pan Head structure with gaskets
Diameter specifications range from ST2.9 to ST6.3
Materials: Carbon steel (surface galvanized/nickel) and stainless steel (sus304 corrosion-resistant)
Strength requirements: ≥ 400MPa for carbon steel grade 8.8, ≥ 700MPa for stainless steel grade A2-70
Complies with international standard ISO 7049

Technical Parameters

Thread Size d	ST2.9	ST3.5	ST4.2	ST4.8	(ST5.5)	ST6.3
P (Pitch)	1.1	1.3	1.4	1.6	1.8	1.8
a (max)	1.1	1.3	1.4	1.6	1.8	1.8
dk (max=nominal size)	7.5	9	10	11.5	13	14.5
dk (min)	6.92	8.42	9.42	10.8	12.3	13.8
k (max=nominal size)	2.35	2.6	3.05	3.55	3.8	4.55
k (min)	2.1	2.35	2.75	3.25	3.5	4.25

Applications

DIN968 self-tapping screws are frequently employed in electrical enclosures, building curtain walls, medical devices, and various other applications. The screws feature a built-in pad design that improves force distribution and are ideal for preventing loosening in thin plates.

Company Certifications

Packaging Options

Carton Packaging

Bolts are packed in neutral packaging boxes, with standard quantities arranged in small cartons. The exact number of units per carton will be confirmed with the customer to align with their specific requirements. Customized packaging configurations are available upon request.

Outer Cartonbox Packaging

The small cartons are then consolidated into larger master cartons for secure transportation and storage. The quantity per master carton can be customized based on client specifications or aligned with standard logistical requirements.

Pallet Packaging

The palletized units are securely wrapped with waterproof film and reinforced with packaging straps. Customer-specific shipping marks or labels are affixed to each pallet, ensuring clear identification and compliance with logistics requirements.
