Hex Head Bolt

DIN6921 Plate Zinc Hexagon Head Bolt for Dependable Long-Lasting Fastening

All Category

Cabinet Gas Spring

Ms. Amylin

amylin@ybfasteners.com

+8618658229310

Contact Now

DIN6921 Plate Zinc Hexagon Head Bolt for Dependable Long-Lasting Fastening

Brand Name:	YONGBIAO
Model Number:	GB/DIN/ISO
MOQ:	800KG
Price:	0.01-0.2USD
Packaging Details:	Carton Box/PE Bag
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Certification:

ISO9001

Class:

8.8,10.9

Shape:

Hex With Flange Head

Trade Term:

EXW,FOB,CIF,DDP,DDU

Surface Treatment:

Plate Zinc

Application Scope:

Automobile Industry

Project:

DIN6921

Threading:

Full Or Half Threaded

Highlight:

Plate Zinc Hexagon Head Bolt

DIN6921 Hexagon Head Bolt

Product Description

Product Description:

DIN6921 Hex Flange Head Bolts

In automobile manufacturing, hexagonal flange bolts are commonly employed to secure engine, chassis, and body components. With their superior strength and corrosion resistance, these bolts are able to meet the strict standards set for automotive parts.

The operational life of a vehicle involves continual vibration. The hexagonal flange bolts, with their broad support area and excellent anti-loosening properties, play a crucial role in maintaining the stability of key components like the engine during driving.

Features:

The fastening is of high quality, with the flange surface resembling a super strong built-in gasket. This feature helps in the even distribution of force, reducing deformation and damage to the connecting parts. It securely fastens parts made of different materials such as metal or plastic.

Compared to standard hexagonal bolts, it offers superior anti-loosening performance. The toothed flange bolt provides even better effectiveness, ensuring stability in high vibration environments like car engines.

There are various options to choose from:

Grade 4.8 is suitable for smaller applications such as home decoration.
Grade 8.8 is commonly used in automobiles and construction machinery.
Grade 10.9 is designed to withstand heavy loads.

Technical Parameters:

DIN6921 Plate Zinc Hexagon Head Bolt for Dependable Long-Lasting Fastening 3

Screw Thread		M5	M6	M8	M10	M12	M14
P		0.8	1	1.25	1.5	1.75	2
b	L≤125	16	18	22	26	30	34
b	125＜L≤200	/	/	28	32	36	40
c	min	1	1.1	1.2	1.5	1.8	2.1
dc	max	11.8	14.2	18	22.3	26.6	30.5
e	min	8.71	10.95	14.26	16.5	17.62	19.86
f	max	1.4	2	2	2	3	3
k	max	5.4	6.6	8.1	9.2	11.5	12.8
s	max	8	10	13	15	16	18
s	min	7.78	9.78	12.73	14.73	15.73	17.73

Application Scope	Automobile Industry
Project	DIN6921
Surface treatment	Plate Zinc
Threading	Full Or Half Threaded
Shape	Hex With Flange Head
Trade Term	EXW, FOB, CIF, DDP, DDU
Class	8.8, 10.9

Applications:

Widely utilized in the automotive industry, mechanical equipment manufacturing, construction of outdoor steel structures, and the production of furniture.

Company Profile:

DIN6921 Plate Zinc Hexagon Head Bolt for Dependable Long-Lasting Fastening 5

Packing and Shipping:


Carton Packaging	Outer Cartonbox Packaging	Pallet Packaging
Bolts are packed in neutral packaging boxes, with standard quantities arranged in small cartons. The exact number of units per carton will be confirmed with the customer to align with their specific requirements. Customized packaging configurations are available upon request.	The small cartons are then consolidated into larger master cartons for secure transportation and storage. The quantity per master carton can be customized based on client specifications or aligned with standard logistical requirements.	The palletized units are securely wrapped with waterproof film and reinforced with packaging straps. Customer-specific shipping marks or labels are affixed to each pallet, ensuring clear identification and compliance with logistics requirements. This final packaging stage guarantees weather-resistant protection and stability during transportation.

FAQ:

Q: What is the brand name of this Hex Head Bolt?
A: The brand name is YONGBIAO.

Q: What is the model number of this Hex Head Bolt?
A: The model number is GB/DIN/ISO.

Q: Where is this Hex Head Bolt manufactured?
A: It is manufactured in CHINA.

Q: What certification does this Hex Head Bolt have?
A: It has ISO9001 certification.

Q: What is the minimum order quantity for this Hex Head Bolt?
A: The minimum order quantity is 800KG.
