Hex Head Bolt

Grade 5-12.9 DIN6921 Hex Flange Head Bolts for Machinery Industry

All Category

Cabinet Gas Spring

Ms. Amylin

amylin@ybfasteners.com

+8618658229310

Contact Now

Grade 5-12.9 DIN6921 Hex Flange Head Bolts for Machinery Industry

Brand Name:	YONGBIAO
Model Number:	DIN6921
MOQ:	50000PCS
Price:	0.03-0.5USD
Packaging Details:	Carton Box/PE Bag
Payment Terms:	TT

Detail Information

Product Description

Detail Information

Place of Origin:

ZHEJAING CHINA

Certification:

ISO9001

Name:

Hex Flange Head Bolt

Drive Type:

External Hex

Application Scrope:

Machinery Industry

Material:

Carbon Steel

Grade:

Grade 5-12.9

Surface Treatment:

Plain ,Zinc Blue ,HDG ,Black,MG

Highlight:

12.9 Hex Flange Head Bolts

DIN6921 Hex Flange Head Bolts

Machinery Industry Hex Flange Bolts

Product Description

Product Description:

DIN6921 Hex Flange Head Bolts In automobile manufacturing, hexagonal flange bolts are used to fix engine, chassis, and body components, and their high strength and corrosion resistance meet the stringent requirements of automotive parts.During the driving process, the car will generate vibration. The large support area and good anti loosening performance of the hexagonal flange bolts can ensure the stability of the connection of key components such as the engine.

Features:

The fastening is very good, and the flange surface is like a built-in super strong gasket, which can evenly distribute the force, reduce the deformation and damage of the connecting parts, and firmly fasten the connecting parts of different materials such as metal or plastic.
Compared to ordinary hexagonal bolts, it has better anti loosening performance, and the toothed flange bolt has better effect, which can maintain stability in high vibration places such as car engines.Multiple options available: Level 4.8 is suitable for small occasions such as home decor;
Grade 8.8 is commonly found in automobiles and construction machinery;Level 10.9 can withstand large loads.

Technical Parameters:

Grade 5-12.9 DIN6921 Hex Flange Head Bolts for Machinery Industry 3

Screw Thread		M5	M6	M8	M10	M12	M14
P		0.8	1	1.25	1.5	1.75	2
b	L≤125	16	18	22	26	30	34
b	125＜L≤200	/	/	28	32	36	40
c	min	1	1.1	1.2	1.5	1.8	2.1
dc	max	11.8	14.2	18	22.3	26.6	30.5
e	min	8.71	10.95	14.26	16.5	17.62	19.86
f	max	1.4	2	2	2	3	3
k	max	5.4	6.6	8.1	9.2	11.5	12.8
s	max	8	10	13	15	16	18
s	min	7.78	9.78	12.73	14.73	15.73	17.73

Applications:

Widely used in automobile manufacturing, mechanical equipment manufacturing, outdoor steel structure connection, and furniture manufacturing.

Grade 5-12.9 DIN6921 Hex Flange Head Bolts for Machinery Industry 4
Company Profile:

Grade 5-12.9 DIN6921 Hex Flange Head Bolts for Machinery Industry 5

Packing and Shipping:


Carton Packaging	Outer Cartonbox Packaging	Pallet Packaging
Bolts are packed in neutral packaging boxes, with standard quantities arranged in small cartons. The exact number of units per carton will be confirmed with the customer to align with their specific requirements. Customized packaging configurations are available upon request.	The small cartons are then consolidated into larger master cartons for secure transportation and storage. The quantity per master carton can be customized based on client specifications or aligned with standard logistical requirements.	The palletized units are securely wrapped with waterproof film and reinforced with packaging straps. Customer-specific shipping marks or labels are affixed to each pallet, ensuring clear identification and compliance with logistics requirements. This final packaging stage guarantees weather-resistant protection and stability during transportation.
